How to install underwater pool lamps?

How to wire pool and swimming pool wall lights in RGB and monochrome modes, and how to install them in civil pools and film pools? First of all, the swimming pool wall lamp is divided into RGB colorful mode and monochrome mode for installation. In RGB mode, a signal synchronization remote control needs to be connected, and the light color effect, jump speed, and brightness of the lamp can be remotely controlled through the touch handle and mobile APP; monochrome mode The installation is relatively simple, just connect a transformer.

Swimming pool wall light RGB mode wiring diagram

Installation instructions for pool pool wall lights in civil pools:

1. Before installation, ensure that the surface of the civil pool wall is flat, attach the installation bracket to the swimming pool wall, and determine the proper position of the installation bracket;

2. Use the round head cross recessed self-tapping stainless steel screws attached to the underwater light to tighten the bracket and make sure the bracket is fixed on the swimming pool wall;

3. Reserve a threading hole in the civil pool wall beside the bracket, pass the wire of the underwater light through the hole, and connect it to the circuit of the transformer or junction box;

4. If there is a TOP logo on the cover of the underwater light, the TOP logo should face up, that is, the direction of 12 o'clock. If there is no TOP mark, the direction of the screw hole is upward, that is, the direction of 12 o'clock;

Civil pool swimming pool wall lamp installation drawing

5. Align the screw holes on the cover of the underwater light with the screw holes on the bracket, and tighten the cover of the underwater light with the cross-recessed countersunk head self-tapping stainless steel screws that come with the light.

Installation instructions for swimming pool wall lights in the film pool:

1. Before installation, ensure that the surface of the film pool is flat, and then open 2 holes of appropriate size on the wall of the film pool;

2. Place the 2 O-rings attached to the underwater light on the bracket, the bracket passes through the film, put the remaining 2 O-rings on the bracket, and then place the 2 transparent waterproof rubber rings on the On the bracket, fix the bracket on the film with hex nuts;

3. Pass the wire of the underwater light through the lock nut, the lock wire waterproof ring and the wire hole of the bracket, and tighten the lock wire nut;

4. The reserved wire is wrapped around the back of the underwater light for future maintenance;

Film pool swimming pool wall lamp installation drawing
5. Align the screw holes on the cover of the underwater light with the screw holes on the bracket, and use the cross-recessed countersunk head self-tapping stainless steel screws that come with the underwater light to tighten the cover of the underwater light.
